Additional Description
Aka Wind steel or steel front, also known as white steel. Means that even if the cooling time of quenching can be cured in air, and very sharp. It is a component of a complex of steel, comprising forming elements tungsten, molybdenum, chromium, vanadium, cobalt carbide. The total amount of alloying elements of about 10 to 25%. It produces fever cases in high-speed cutting (about 500 ℃) still maintain high hardness, HRC can in 60 or more. This is the most important characteristic of high speed steel - red hardness. And the carbon tool steel after quenching and tempering, at room temperature, although the high hardness, but when the temperature is higher than 200 ℃, the hardness will be decreased drastically, 500 ℃ hardness in the annealed condition and has been reduced to a similar extent completely lost the ability to cut the metal, which limits the production of carbon tool steel cutting tools. The high-speed steel due to good red hardness, to make up for the shortcomings deadly carbon tool steel, can be used to manufacture cutting tools.
Grade
GB9943 | ISO 4957 | JIS | AISI | ERASTEEL | BOHLER |
W2Mo9Cr4VCo8 | HS2-9-1-8 | SKH59 | M42 | EM42 | S500 |
W6Mo5Cr4V2Co5 | HS6-5-2-5 | SKH55 | (M35) | EM35 | S705 |
W7Mo4Cr4V2Co5 | M41 | ||||
W12Cr4V5Co5 | HS12-1-5-5 | SKH10 | T15 | ||
W10Mo4Cr4V3Co10 | HS10-4-3-10 | SKH57 | (T42) | WKE42 | S700 |
W6Mo5Cr4V2Al | S620 | ||||
W6Mo5Cr4V3 | HS6-5-3 | SKH53 | M3-2 | EM3:2 | S607 |
CW6Mo5Cr4V3 | HS6-5-3C | ||||
W6Mo5Cr4V4 | HS6-5-4 | SKH54 | M4 | ||
W6Mo5Cr4V2 | HS6-5-2 | SKH51 | M2 | ||
W6Mo5Cr4V2 | HS6-5-2 | SKH51 | M2 | ||
CW6Mo5Cr4V2 | HS6-5-2C | CM2 | EM2 | S600 | |
W6Mo6Cr4V2 | HS6-6-2 | ||||
(W6Mo3Cr4V2) | |||||
W9Mo3Cr4V | |||||
W2Mo8Cr4V | HS1-8-1 | M1 | |||
W2Mo9Cr4V2 | HS2-9-2 | SKH58 | M7 | EM7 | S400 |
W18Cr4V | HS18-0-1 | SKH2 | T1 | ET1 | S200 |
W1Mo4Cr4V2 | HS1-4-2 | M52 | |||
W4Mo3Cr4VSi | |||||
W3Mo3Cr4V2 | HS3-3-2 | ABCⅢ | |||
(W3Mo2Cr4V2Si) |
Craftwork&Size
Thickness(mm) | Width(mm) | Length(mm) | |
Hot rolled | 10 - 90 | 20 - 600 | 100-5000 |
Cold rolled | 0.1 - 10 | 10-1000 | 100-3000 |
Forging | 25-280 | 50 - 500 | 100-2000 |
Pre hardened | 3 - 90 | 20 - 300 | 20-500(HRC60-69 ) |
Depending on your needs |
